Product pictures of knuckle joint-flexible elbow joint
The knuckle joint (also named the flexible elbow joint), used with the salvage equipment, can withstand tension, compression, torsion, impact and other loads, catch the big fish with more bigger inclination, and grasp the shelter fishes which fall into “belly” or on the top s. It is an auxiliary fishing tool.
Specification of knuckle joint-flexible elbow joint
|
Type |
O.D.(mm) |
I.D.(mm) |
Bending angle(°) |
Connection |
Type |
O.D.(mm) |
I.D.(mm) |
Bending angle(°) |
Connection |
|
KJ102 |
102 |
25 |
7 |
NC31 |
KJ190 |
190 |
80 |
7 |
NC50 |
|
KJ108 |
108 |
35 |
7 |
NC31 |
KJ200 |
200 |
85 |
7 |
NC50 |
|
KJ120 |
120 |
45 |
7 |
NC31 |
KJ210 |
210 |
90 |
7 |
6-5/8 REG |
|
KJ146 |
146 |
60 |
7 |
NC38 |
KJ222 |
222 |
100 |
7 |
6 5/8″ REG |
|
KJ165 |
165 |
70 |
7 |
NC50 |
KJ244 |
244 |
110 |
7 |
6 5/8″ REG |
|
KJ184 |
184 |
75 |
7 |
NC50 |
|
|
|
|
|
|
|
