API 6A gate valve (flange end gate valve)
Specifications of API 6A gate valve (flange end gate valve)
1). Standard:API 6A.
2). Size: 1-13/16" - 9"
3). Pressure:2000PSI~20000PSI
API 6A gate valve (flange end gate valve)
API 6A gate valve (flange end gate valve) are mostly used to all sorts of Wellhead Christmas Trees and manifolds and casing valve, etc.,
with working pressure such as 3000/5000psi, 10000psi and 15000psi, inside nominal diameter 1-13/16" ,
2-1/16" ,2-9/16",3-1/16",-4-1/16",7-1/16" ,satisfy all requirements for geologic exploration and oil production.
Requirement for material, physical and chemical data and pressure test conform to API 6A, 20th edition.
|
Working pressure |
2000PSI~20000PSI |
|
Nominal Bore |
1-13/16"~9" (46mm~230mm) |
|
Working Medium |
oil,natural gas,mud and gas containing H2S,CO2 |
|
Working Temperature |
-46°C~121°C(Class LU) |
|
Material Class |
AA,BB,CC,DD,EE,FF,HH |
|
Specification level |
PSL1-3 |
|
Performance Requirement |
PR1 |
