    releasing slip overshot
    Product Name:
    releasing slip overshot
    No. :
    :
    :

    Product Description

    releasing slip overshot

    Product pictures of releasing slip overshot


    releasing slip overshot-Releasing and Circulating Overshots (spiral grapple) are the industry standard for external catch fishing tools. With a proven track record and the highest quality construction and design, the releasing slip overshott is the efficient and cost effective tool for Fishing companies all over the world.

    Features of our releasing slip overshot



     Durable construction

     Proven design

     Left hand helix with a tapered exterior

     Interior is wickered for engagement with the fish

    Accessories:

     Extension Subs

     Oversize Guides

     Wall Hook Guides

     Milling Shoes

     Lock Rings

    Our releasing slip overshot(basket grapple) are the industry standard for external catch fishing tools. With a proven track record and the highest quality construction and design, releasing slip overshot is the efficient and cost effective tool for Fishing companies all over the world.

    A Basket Grapple is an expandable cylinder with a tapered exterior to conform to the helically tapered section in the Bowl. Its interior is wickered for engagement with the fish. Two types of Basket Grapple are available to meet the need for catching various types of fish.

    Features:The Basket Grapple with Long Catch Stop has an internal shoulder located at the upper end, to stop the fish in the best catch position. It is designed to stop and catch collars and tool joints, with sufficient length left below the Grapple to allow the joint to be packed-off with a Basket Control Packer. The Basket Grapple with Short Catch Stop (not shown) has a double set of wickers of two different internal diameters. It is used to stop and catch a coupling with a ruptured piece of pipe engaged in its upper end. The upper set of wickers will catch the ruptured pipe and act as a stop against the coupling, while the lower set of wickers will catch the coupling.

    Accessories:

     Extension Subs

     Oversize Guides

     Wall Hook Guides

     Milling Shoes

     Lock Rings

    Specification of releasing slip overshot







    Type



    O.D

    (mm)



    Max Size of Fish(mm)



    API

    Connection



    Type



    (mm)O.D



    Max Size of Fish(mm)



    API

    Connection

    Spiral Grapple

    Basket Grapple

    Spiral Grapple

    Basket Grapple

    LT-T89

    89

    60.3

    47.6

    NC26

    LT-T194

    194

    159

    141

    NC50

    LT-T92

    92

    73

    63.5

    NC26

    LT-T200

    200

    159

    141

    NC50

    LT-T95

    95

    76.2

    66.6

    NC26

    LT-T206

    206

    178

    163

    NC50

    LT-T102

    102

    73

    60.3

    NC26

    LT-T206A

    206

    168

    152

    NC50

    LT-T105

    105

    85.7

    73

    NC31

    LT-T219

    219

    178

    159

    NC50

    LT-T114

    114

    89

    75

    NC31

    LT-T232

    232

    203

    187

    NC50

    LT-T117

    117

    89

    78

    NC31

    LT-T244

    244

    206

    184

    6 5/8 REG

    LT-T127

    127

    95

    80

    NC38

    LT-T260

    260

    219

    200

    6 5/8 REG

    LT-T143

    143

    120.6

    102

    NC38

    LT-T270

    270

    228.6

    209.6

    6 5/8 REG

    LT-T152

    152

    128

    111

    NC38

    LT-T273

    273

    241.3

    216

    6 5/8 REG

    LT-T168

    168

    127

    114

    NC50

    LT-T286

    286

    244.5

    225.4

    6 5/8 REG

    LT-T168B

    168

    139.7

    120.6

    NC50

    LT-T298A

    298

    257

    238.1

    6 5/8 REG

    LT-T181

    181

    146

    127

    NC50

    LT-T340

    340

    286

    260

    6 5/8 REG




    My friend, if you have any requests of our releasing slip overshot, please send your requests to my email: sales@chancematewellcontrol.com, we are 24 hours online to give you the best service
